CAV24C32YE-GT3

PROM 串行 I²C，ON Semiconductor### EEPROM 串行存取 - ON Semiconductor

The CAV24C32 is a 32-kb CMOS Serial EEPROM devices, internally organized as 4096 words of 8 bits each.It features a 32-byte page write buffer and supports the Standard 100 kHz and Fast 400 kHz IExternal address pins make it possible to address up to eight CAV24C32 devices on the same bus.

Features |   | Benefits

---|---|---

 | |  | |  |

.

Automotive Temperature Grade 1 -40°C to +125°C

|   |

.

Allows the use in safety critical application.

.

2.5 V to 5.5 V Supply Voltage Range

|   |

.

Single power supply from 2.5V to 5.5V. Functional over the entire Temperature range.

.

This Device is Pb-Free, Halogen Free/BFR Free, and RoHS Compliant

|   |

.

Space-Efficient Packaging

.

Supports Standard and Fast I2C Protocol

|   |

.

32-Byte Page Write Buffer

|   |

.

Hardware Write Protection for Entire Memory

|   |

.

CAV Prefix for Automotive and Other Applications Requiring Site and Change Control

|   |

.

Schmitt Triggers and Noise Suppression Filters on I2C Bus InputsSCL and SDA

|   |

.

Low Power CMOS Technology

|   |

.

1,000,000 Program/Erase Cycles

|   |

.

100 Year Data Retention

|   |

.

SOIC, TSSOP 8-lead Packages

|   |
