2 - KB和4 KB的I2C串行EEPROM部分阵列写保护 2-Kb and 4-Kb I2C Serial EEPROM with Partial Array Write Protection
Description
The CAT24C03/05 is a 2−Kb/4−Kb CMOS Serial EEPROM device organized internally as 16/32 pages of 16 bytes each, for a total of 256x8/512x8 bits. These devices support both Standard 100 kHz as
well as Fast 400 kHz I2C protocol.
Features
•Supports Standard and Fast I2C Protocol
•1.8 V to 5.5 V Supply Voltage Range
•16−Byte Page Write Buffer
•Hardware Write Protection for Upper Half of Memory
•Schmitt Triggers and Noise Suppression Filters on I2C Bus InputsSCL and SDA
•Low Power CMOS Technology
•1,000,000 Program/Erase Cycles
•100 Year Data Retention
•Industrial Temperature Range
•These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
