CMOS和盖茨 CMOS AND GATES
CD4073B, CD4081B and CD4082B AND gates, provide the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates.
The CD4073B, CD4081B, and CD4082B types are supplied in 14-lead hermetic dual-in-line ceramic packages F3A suffix, 14-lead dual-in-line plastic packages E suffix, 14-lead small-outline packages M, MT, M96, and NSR suffixes, and 14-lead thin shrink small-outline packages PW and PWR suffixes.
得捷:
IC GATE AND 2CH 4-INP 14TSSOP
立创商城:
CD4082BPWR
德州仪器TI:
2-ch, 4-input, 3-V to 18-V AND gates
贸泽:
逻辑门 CMOS Dual 4-Input AND Gate
艾睿:
AND Gate 2-Element 4-IN CMOS 14-Pin TSSOP T/R
安富利:
AND Gate 2-Element 4-IN CMOS 14-Pin TSSOP T/R
Chip1Stop:
AND Gate 2-Element 4-IN CMOS 14-Pin TSSOP T/R
Verical:
AND Gate 2-Element 4-IN CMOS 14-Pin TSSOP T/R
DeviceMart:
IC DUAL 4INPUT AND GATE 14TSSOP
Win Source:
AND Gate IC 2 Channel 14-TSSOP
电源电压DC 3.00V ~ 18.0V
输出接口数 1
输出电流 6.80 mA
电路数 2
位数 2
传送延迟时间 250 ns
电压波节 5.00 V, 10.0 V, 15.0 V
逻辑门个数 2
输出电流驱动 -1.00 mA
输入数 4
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 3V ~ 18V
电源电压Max 18 V
电源电压Min 3 V
安装方式 Surface Mount
引脚数 14
封装 TSSOP-14
长度 5 mm
宽度 4.4 mm
高度 1.15 mm
封装 TSSOP-14
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CD4082BPWR TI 德州仪器 | 当前型号 | 当前型号 |
CD4082BPWRE4 德州仪器 | 完全替代 | CD4082BPWR和CD4082BPWRE4的区别 |
CD4082BPWE4 德州仪器 | 完全替代 | CD4082BPWR和CD4082BPWE4的区别 |
CD4082BPWG4 德州仪器 | 完全替代 | CD4082BPWR和CD4082BPWG4的区别 |
