CR1206-FX-2052ELF

CR1206-FX-2052ELF图片1
CR1206-FX-2052ELF图片2
CR1206-FX-2052ELF图片3
CR1206-FX-2052ELF图片4
CR1206-FX-2052ELF图片5
CR1206-FX-2052ELF概述

Res Thick Film 1206 20.5KΩ 1% 0.25W1/4W ±100ppm/℃ Molded SMD SMD Paper Tape on Plastic Reel

20.5 kOhms ±1% 0.25W, 1/4W Chip Resistor 1206 3216 Metric Moisture Resistant Thick Film


得捷:
RES SMD 20.5K OHM 1% 1/4W 1206


艾睿:
The CR1206-FX-2052ELF fixed single surface-mount resistor from Bourns makes it easy to add resistors to your circuit board. This product has a resistance value of 20.5K Ohm. This dependable part has a power rating of 0.25 1/4 W. Its temperature coefficient is ±100 ppm/°C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This part has an operating temperature of -55 to 155 °C. This device is made with thick film technology. It has a tolerance of 1%.


安富利:
Res Thick Film 1206 20.5K Ohm 1% 1/4W ±100ppm/°C Molded SMD SMD Paper Tape on Plastic Reel


Electro Sonic:
Res Thick Film 1206 20.5K Ohm 1% 0.25W1/4W ±100ppm/°C Pad SMD T/R


CR1206-FX-2052ELF中文资料参数规格
技术参数

容差 ±1 %

额定功率 0.25 W

产品系列 CR

电阻 20.5 kΩ

阻值偏差 ±1 %

工作温度Max 155 ℃

工作温度Min -55 ℃

封装参数

封装公制 3216

封装 1206

外形尺寸

长度 3.20 mm

宽度 1.60 mm

高度 0.6 mm

封装公制 3216

封装 1206

厚度 610 µm

物理参数

工作温度 -55℃ ~ 155℃

温度系数 ±100 ppm/℃

其他

产品生命周期 Active

包装方式 Tape & Reel TR

最小包装 5000

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买CR1206-FX-2052ELF
型号: CR1206-FX-2052ELF
制造商: Bourns J.W. Miller 伯恩斯
描述:Res Thick Film 1206 20.5KΩ 1% 0.25W1/4W ±100ppm/℃ Molded SMD SMD Paper Tape on Plastic Reel
