多层片状电感器 Multi-Layer Chip Inductors
3.3nH Unshielded Multilayer Inductor 300mA 160mOhm Max 0402 1005 Metric
立创商城:
3.3nH ±0.3nH 160mΩ
得捷:
FIXED IND 3.3NH 300MA 160MOHM SM
艾睿:
This chip CI100505-3N3D surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This device is made with multi-layer technology. This product is 1.05 mm long, 0.55 mm tall and 0.55 mm deep. This SMD inductor has a maximum DC current of 300m A with a maximum resistance of 160m Ohm. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 6G Hz. It has an inductance of 3.3n H.
安富利:
Ind Chip Multi-Layer 3.3nH 0.3nH 100MHz 8Q-Factor Ceramic 300mA 0402 T/R
Chip1Stop:
Inductor Chip Multi-Layer 3.3nH 0.3nH 100MHz 8Q-Factor Ceramic 300mA 160mOhm DCR 0402 T/R
Verical:
Inductor RF Multi-Layer 0.0033uH 0.3nH 100MHz 8Q-Factor Ceramic 0.3A 0.16Ohm DCR 0402 Automotive T/R
MASTER:
Inductor RF Multi-Layer 0.0033uH 0.3nH 100MHz 8Q-Factor Ceramic 0.3A 0.16Ohm DCR 0402 Automotive T/R
Electro Sonic:
Inductor RF Multi-Layer 0.0033uH 0.3nH 100MHz 8Q-Factor Ceramic 0.3A 0.16Ohm DCR 0402 Automotive T/R
额定电流 300 mA
电感 3.3 nH
自谐频率 6 GHz
Q值 8.0
电感公差 ±0.3 nH
测试频率 100 MHz
电阻DC) ≤160 mΩ
工作温度Max 125 ℃
工作温度Min -55 ℃
电阻DC Max 160 mΩ
安装方式 Surface Mount
封装公制 1005
封装 0402
长度 1.05 mm
宽度 0.55 mm
高度 0.55 mm
封装公制 1005
封装 0402
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504508000
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CI100505-3N3D Bourns J.W. Miller 伯恩斯 | 当前型号 | 当前型号 |
PE-0402CC3N3STT 普思电子 | 功能相似 | CI100505-3N3D和PE-0402CC3N3STT的区别 |
