CF18JT2K40

2.4kΩ ±5% 0.125W1/8W 0/-400ppm/℃ Φ1.70mm

2.4 kOhms ±5% 0.125W，1/8W 轴向 通孔器 阻燃涂层，安全 炭膜

得捷:
RES 2.4K OHM 5% 1/8W AXIAL

艾睿:
In addition to being very cost-effective, the CF18JT2K40 fixed single through-hole resistor, developed by SEI Stackpole Electronics, is very easy to solder onto any printed circuit board. This part has a power rating of 0.125 1/8 W. This product has a resistance value of 2.4K Ohm. Its temperature coefficient is -400 to 0 ppm/°C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. It has a tolerance of 5%. This product is 3.3 mm long. The CF18JT2K40 part has an axial termination style. This device utilizes carbon film technology. This part has an operating temperature of -55 to 155 °C.

安富利:
Res Carbon Film 2.4K Ohm 5% 1/8W -400ppm/°C to 0ppm/°C Conformal AXL Thru-Hole T/R

Chip1Stop:
Res Carbon Film 2.4K Ohm 5% 0.125W1/8W -400ppm/C to 0ppm/C Conformal Coated AXL T/R

Verical:
Res Carbon Film 2.4K Ohm 5% 0.125W1/8W -400ppm/C to 0ppm/C Conformal Coated AXL T/R
