16位缓冲器/驱动器,具有三态输出 16-BIT BUFFER/DRIVER WITH 3-STATE OUTPUTS
缓冲器,非反向 元件 4 位每元件 三态 Output 48-TSSOP
立创商城:
CLVC16244AIDGGRQ1
德州仪器TI:
Automotive 16-ch, 1.65-V to 3.6-V buffers with 3-state outputs
得捷:
IC BUF NON-INVERT 3.6V 48TSSOP
贸泽:
Buffers & Line Drivers Auto Cat 16-Bit Buff/Drv W/3-St Otpt
艾睿:
Amplify analog and digital signals by driving the input to the transmission line with this CLVC16244AIDGGRQ1 buffer and line driver from Texas Instruments. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -40 °C to 85 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This non-inverting device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 3.6 V. It has 16 channels per chip.
Verical:
Buffer/Line Driver 16-CH Non-Inverting 3-ST CMOS Automotive 48-Pin TSSOP T/R
Win Source:
IC BUFF/DVR 3-ST 16BIT 48TSSOP
电源电压DC 3.60V max
输出接口数 16
通道数 16
位数 16
电压波节 3.30 V, 2.70 V, 2.50 V, 1.80 V
输出电流驱动 -1.00 mA
输入数 16
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 48
封装 TSSOP-48
长度 12.5 mm
宽度 6.1 mm
高度 1.15 mm
封装 TSSOP-48
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CLVC16244AIDGGRQ1 TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVC162244ADGGR 德州仪器 | 类似代替 | CLVC16244AIDGGRQ1和SN74LVC162244ADGGR的区别 |
SN74LVC16244ADGGR 德州仪器 | 类似代替 | CLVC16244AIDGGRQ1和SN74LVC16244ADGGR的区别 |
SN74LVCH162244AGR 德州仪器 | 类似代替 | CLVC16244AIDGGRQ1和SN74LVCH162244AGR的区别 |
