CC453232-100KL

BOURNS  CC453232-100KL  表面贴装功率电感器, CC453232系列, 10 µH, ± 10%, 绕线, 0.5 ohm

Bourns 1812 CC45 系列线绕器

高电流额定值

电感范围 1 μH 至 680 μH

符合 RoHS

移动电话、手机和 CTV、VCR、HTC、FDD 中的应用

### 表面安装 1812 电感器（扼流圈）

得捷:
FIXED IND 10UH 550MA 500MOHM SMD

立创商城:
10uH ±10% 550mA 500mΩ

欧时:
### Bourns 1812 CC45 系列线绕电感器高电流额定值 电感范围 1 μH 至 680 μH 符合 RoHS 移动电话、手机和 CTV、VCR、HTC、FDD 中的应用 ### 表面安装 1812 电感器（扼流圈）

e络盟:
功率电感SMD, 10 µH, 绕线, 550 mA, CC453232系列, 4.2mm x 3.2mm x 3.2mm

艾睿:
This chip CC453232-100KL surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has a tolerance of 10%. This SMD inductor has a maximum DC current of 550m A with a maximum resistance of 500m Ohm. Its test frequency is 2.52M Hz, while its minimum self-resonant frequency is 22M Hz. This product is 4.8 mm long, 3.4 mm tall and 3.4 mm deep. This device is made with wirewound technology. It has an inductance of 10u H.

安富利:
Ind Chip Wirewound 10uH 10% 2.52MHz 10Q-Factor Ferrite 550mA 1812 T/R

Chip1Stop:
Ind Chip Wirewound 10uH 10% 2.52MHz 10Q-Factor Ferrite 550mA 4.5 x 3.2 mm T/R

Verical:
Inductor General Purpose Chip Wirewound 10uH 10% 2.52MHz 10Q-Factor Ferrite 0.55A 0.5Ohm DCR 1812 T/R

Newark:
# BOURNS  CC453232-100KL  Surface Mount Power Inductor, CC453232 Series, 10 H, 10%, Wirewound, 0.5 ohm

MASTER:
Inductor Power - Chip - Wirewound - 10 uH - 2.52 MHz - Ferrite - 550 mA - 500 mOhm.

Electro Sonic:
Inductor Power - Chip - Wirewound - 10 uH - 2.52 MHz - Ferrite - 550 mA - 500 mOhm.
