CM453232-101JL

BOURNS  CM453232-101JL  电感, 100uH, 5%容差, 1812封装

无屏蔽 绕线 器 8 欧姆最大 1812（4532 公制）

得捷:
FIXED IND 100UH 110MA 8 OHM SMD

欧时:
MAGNETICS - CHIP INDUCTOR

立创商城:
100uH ±5% 8Ω

贸泽:
Fixed Inductors 100uH 5%

e络盟:
高频电感器, 100 µH, CM45 Series, 110 mA, 1812 [4532 公制], 绕线, 8 ohm

艾睿:
This general purpose chip CM453232-101JL surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. It has a tolerance of 5%. It has an inductance of 100u H. Its test frequency is 2.52M Hz, while its minimum self-resonant frequency is 8M Hz. This product is 4.8 mm long, 3.4 mm tall and 3.4 mm deep. This SMD inductor has a maximum DC current of 110m A with a maximum resistance of 8 Ohm. This device is made with wirewound technology.

安富利:
Ind General Purpose Chip Wirewound 100uH 5% 2.52MHz 40Q-Factor Ferrite 110mA 1812 T/R

Chip1Stop:
Ind General Purpose Chip Wirewound 100uH 5% 2.52MHz 40Q-Factor Ferrite 110mA 4.5 x 3.2 mm T/R

Verical:
Inductor General Purpose Chip Wirewound 100uH 5% 796KHz 40Q-Factor Ferrite 0.11A 8Ohm DCR 1812 T/R

Newark:
Surface Mount High Frequency Inductor, CM453232 Series, 100 µH, 110 mA, 1812 [4532 Metric]

MASTER:
Inductor General Purpose Chip Wirewound 100uH 5% 796KHz 40Q-Factor Ferrite 0.11A 8Ohm DCR 1812 T/R

Electro Sonic:
Inductor General Purpose Chip Wirewound 100uH 5% 796KHz 40Q-Factor Ferrite 0.11A 8Ohm DCR 1812 T/R
