8位锁存器 8-Bit Latches
D 型透明 1 通道 8:8 IC 三态 20-SSOP
得捷:
IC 8BIT OCT TRNSP D LATCH 20QSOP
立创商城:
CY74FCT373ATQCT
德州仪器TI:
Octal Transparent D-Type Latches with 3-State Outputs
贸泽:
闭锁 Tri-State 8-Bit
艾睿:
This d-type CY74FCT373ATQCT low-level latch from Texas Instruments is a staple for any circuit designer. With a 3-state output, this is power management at its best. This latch has an operating temperature range of -40 °C to 85 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.75 V, while its maximum is 5.25 V.
安富利:
Latch Transparent 3-ST 8-CH D-Type 20-Pin SSOP T/R
Chip1Stop:
Latch Transparent 3-ST 8-CH D-Type 20-Pin SSOP T/R
Verical:
Latch Transparent 3-ST 8-CH D-Type 20-Pin SSOP T/R
Win Source:
IC 8BIT OCT TRNSP D LATCH 20QSOP
电源电压DC 5.00 V, 5.25 V max
输出接口数 8
输出电流 64.0 mA
电路数 1
位数 8
极性 Non-Inverting
电压波节 5.00 V
静态电流 100 µA
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.75V ~ 5.25V
电源电压Max 5.25 V
电源电压Min 4.75 V
安装方式 Surface Mount
引脚数 20
封装 SSOP-20
长度 8.75 mm
宽度 4 mm
高度 1.5 mm
封装 SSOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CY74FCT373ATQCT TI 德州仪器 | 当前型号 | 当前型号 |
CY74FCT373ATQC 德州仪器 | 完全替代 | CY74FCT373ATQCT和CY74FCT373ATQC的区别 |
CY74FCT373ATQCTE4 德州仪器 | 类似代替 | CY74FCT373ATQCT和CY74FCT373ATQCTE4的区别 |
CY74FCT373CTQCT 德州仪器 | 类似代替 | CY74FCT373ATQCT和CY74FCT373CTQCT的区别 |
