16位寄存器 16-Bit Registers
If you are looking for a simple device that can store state information, look no further than Texas Instruments" flip flop device. With a 3-state output, this is power management at its best. It has a single-ended output signal. This flip flop has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device comes in tube packaging. It has 16 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
电源电压DC 5.50V max
输出接口数 8
输出电流 64.0 mA
位数 16
极性 Non-Inverting
电压波节 5.00 V
输入电容 4.5 pF
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
安装方式 Surface Mount
引脚数 48
封装 BSSOP-48
封装 BSSOP-48
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CY74FCT16374ATPVCT TI 德州仪器 | 当前型号 | 当前型号 |
CY74FCT16374CTPVCT 德州仪器 | 完全替代 | CY74FCT16374ATPVCT和CY74FCT16374CTPVCT的区别 |
CY74FCT16374ATPVC 德州仪器 | 类似代替 | CY74FCT16374ATPVCT和CY74FCT16374ATPVC的区别 |
74FCT16374ATPVCG4 德州仪器 | 类似代替 | CY74FCT16374ATPVCT和74FCT16374ATPVCG4的区别 |
