CRA2512-FZ-R010ELF

BOURNS  CRA2512-FZ-R010ELF  功率电阻, 0.01Ω, 0.01, 2512, 整卷

CRA 系列 2512 格式 - 电流感应

特制合金器

70°C 时的功率额定值为 3 瓦特

电感小于 5 nH

### 产品应用信息

这些电流感应电阻器符合 AEC-Q200 且适用于汽车应用。

### 标准

符合 AEC-Q200

得捷:
RES 0.01 OHM 1% 3W 2512

欧时:
### CRA 系列 2512 格式 - 电流感应特制合金电阻器 70°C 时的功率额定值为 3 瓦特 电感小于 5 nH ### 产品应用信息这些电流感应电阻器符合 AEC-Q200 且适用于汽车应用。 ### 标准符合 AEC-Q200### 电流感应 - 表面安装金属片式电阻器 低热电动势 无电感性 3 位电阻代码标记 小型卷轴适合于小批量生产、开发和研发部门 适合于在拾放式机械上自动装配

立创商城:
10mΩ ±1% 3W

e络盟:
电流感应电阻器, 表面安装, 0.01 ohm, CRA Series, 2512 [6432公制], 3 W, ± 1%, 金属条

艾睿:
Use this CRA2512-FZ-R010ELF fixed single surface-mount resistor from Bourns to obtain a visually clean layout. This product has a resistance value of 10m Ohm. This part has a power rating of 3 W. It is also complete with current sensing technology. Its temperature coefficient is ±75 ppm/°C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This product is 6.45 mm long, 0.7 mm tall and 3.35 mm deep. This device is made with thick film technology. This part has an operating temperature of -55 to 170 °C. It has a tolerance of 1%.

Allied Electronics:
Resistor; Metal Film; Res 0.01 Ohms; Pwr-Rtg 3 W; Tol 1%; SMT; 2512; Current Sense

安富利:
Res 2512 0.01 Ohm 1% 3W ±75ppm/°C Molded SMD SMD T/R

Chip1Stop:
Res Thick Film 2512 0.01 Ohm 1% 3W ±75ppm/ÂÂ℃ Molded SMD Embossed T/R

Verical:
Res Metal Strip 2512 0.01 Ohm 1% 3W ±50ppm/C Pad SMD Automotive T/R

Newark:
# BOURNS  CRA2512-FZ-R010ELF  SMD Current Sense Resistor, 0.01 ohm, 3 W, 2512 [6432 Metric], ± 1%, CR Series

MASTER:
SMD Current Sense Resistor - 2512 [6432 Metric] - 0.01 Ohm - 3W - ±50ppm/°C - Metal Film.

Electro Sonic:
SMD Current Sense Resistor - 2512 [6432 Metric] - 0.01 Ohm - 3W - ±50ppm/°C - Metal Film.

Win Source:
RES 0.01 OHM 1% 3W 2512 / 10 mOhms ±1% 3W Chip Resistor 2512 6432 Metric Automotive AEC-Q200, Current Sense, Moisture Resistant Metal Element
