CMP04FS-REEL

Comparator Quad ±18V/36V 14Pin SOIC N T/R

Product Details

Four precision independent comparators comprise the CMP04. Performance highlights include a very low offset voltage, low output saturation voltage and high gain in a single supply design. The input voltage range includes ground for single supply operation and V- for split supplies. A low power supply current of 2 mA, which is independent of supply voltage, makes this the preferred comparator for precision applications requiring minimal power consumption. Maximum logic interface flexibility is offered by the open-collector TTL output.

### Features and Benefits

.

High Gain: 200 V/mV Typ

.

Single- or Dual-Supply Operation

.

Input Voltage Range Includes Ground

.

Low Power Consumption 1.5 mW/Comparator

.

Low Input Bias Current: 100 nA Max

.

Low Input Offset Current: 10 nA Max

.

Low Offset Voltage: 1 mV Max

.

Low Output Saturation Voltage: 250 mV @ 4 mA

.

Logic Output Compatible with TTL, DTL, ECL, MOS, and CMOS

.

Directly Replaces LM139/LM239/LM339 Comparators
