固态继电器-工业安装 DIN SSR 530VAC/10A , 90-280VAC In,ZC
SOLID STATE RELAY 48-530 V - DIN SSR 530VAC/10A, 90-280VAC In,TP,ZC
得捷:
SSR RELAY SPST-NO 10A 48-530V
贸泽:
固态继电器-工业安装 DIN SSR 530VAC/10A , 90-280VAC In,ZC
Allied Electronics:
DIN SSR 530VAC/10A, 90-280VAC In, ZC
MASTER:
SOLID STATE RELAY 48-530 V - DIN SSR 530VAC/10A, 90-280VAC In,TP,ZC
Online Components:
SOLID STATE RELAY 48-530 V - DIN SSR 530VAC/10A, 90-280VAC In,TP,ZC
Electro Sonic:
SOLID STATE RELAY 48-530 V - DIN SSR 530VAC/10A, 90-280VAC In,TP,ZC
触点类型 SPST-NO
负载电流 10 A
输入电流 5 mA
输入电流Min 4 mA
工作温度Max 80 ℃
工作温度Min -40 ℃
输入电压 90VAC ~ 280VAC
安装方式 Screw
引脚数 4
封装 SSR with Integrated Heat Sink
长度 81.3 mm
宽度 22.5 mm
高度 99 mm
封装 SSR with Integrated Heat Sink
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536490080
