VISHAY CRCW0805330RJNEAIF 片式电阻器, 表面贴装, 厚膜, AEC-Q200 CRCW系列, 330 ohm, 150 V, 0805 [2012公制], 125 mW, ± 5%
The Vishay D/CRCW-IF e3 series Lead Pb-free thick film, rectangular, pulse proof chip resistors. The D/CRCW-IF e3 series resistors have Pure tin plating which provides compatibility with lead Pb-free and lead containing soldering processes.
- .
- High pulse performance
- .
- Metal glaze on high quality ceramic
- .
- Protective overglaze
- .
- Excellent stability ΔR/R
- .
- Lead Pb-free solder contacts on Ni barrier layer
容差 ±5 %
额定功率 125 mW
电阻 330 Ω
阻值偏差 ±5 %
工作温度Max 155 ℃
工作温度Min -55 ℃
额定电压 150 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.45 mm
封装公制 2012
封装 0805
温度系数 ±200 ppm/K
包装方式 Cut Tape CT
制造应用 Industrial, 便携式器材, Automotive, 工业, 消费电子产品, 车用, Consumer Electronics, Portable Devices, 电源管理, Power Management
RoHS标准 RoHS Compliant
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CRCW0805330RJNEAIF Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
ERJ6GEYJ331V 松下 | 类似代替 | CRCW0805330RJNEAIF和ERJ6GEYJ331V的区别 |
