0201 1 uF 6.3 V ±10 % 容差 X5R 表面贴装 多层陶瓷电容
MLCC-多层陶瓷器
得捷:
CAP CER 1UF 6.3V X5R 0201
立创商城:
1uF ±10% 6.3V
艾睿:
This CL03A105KQ3CSNC multilayer ceramic capacitor from Samsung Electro-Mechanics is non-polarized so it may be connected either to positive or to negative voltage. It can withstand a voltage of 6.3 VDC. This MLCC capacitor has a maximum operating temperature of 85 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This product is 0.6 mm long, 0.3 mm tall and 0.3 mm deep. Its capacitance value is 1uF. It has a tolerance of 10%.
安富利:
Cap Ceramic 1uF 6.3V X5R 10% SMD 0201 85°C Cardboard T/R
Verical:
Cap Ceramic 1uF 6.3V X5R 10% Pad SMD 0201 85C T/R
额定电压DC 6.3 V
绝缘电阻 10 GΩ
电容 1 µF
容差 ±10 %
产品系列 Acoustic Noise
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压 6.3 V
安装方式 Surface Mount
封装公制 0603
封装 0201
长度 0.6 mm
宽度 0.3 mm
高度 0.3 mm
封装公制 0603
封装 0201
厚度 0.3 mm
材质 X5R/-55℃~+85℃
工作温度 -55℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CL03A105KQ3CSNC Samsung 三星 | 当前型号 | 当前型号 |
CL03A105KQ3CSNH 三星 | 完全替代 | CL03A105KQ3CSNC和CL03A105KQ3CSNH的区别 |
CL03A105MQ3CSNH 三星 | 类似代替 | CL03A105KQ3CSNC和CL03A105MQ3CSNH的区别 |
CL03A105MQ3CSNC 三星 | 类似代替 | CL03A105KQ3CSNC和CL03A105MQ3CSNC的区别 |
