1210 150nF ±10% 50V X7R
±10% 50V 陶瓷器 X7R 1210(3225 公制)
得捷:
CAP CER 0.15UF 50V X7R 1210
艾睿:
Get more with less with Samsung Electro-Mechanics&s; CL32B154KBFNNNE multilayer ceramic capacitor which uses multiple layers of ceramic and metal to act as dielectric and electrodes. It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 3.2 mm long, 1.25 mm tall and 2.5 mm deep. It has a tolerance of 10%. Its capacitance value is 0.15uF.
儒卓力:
**KC 150nF 1210 10% 50V X7R **
额定电压DC 50.0 V
电容 0.15 µF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 3225
封装 1210
长度 3.2 mm
宽度 2.5 mm
高度 1.25 mm
封装公制 3225
封装 1210
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CL32B154KBFNNNE Samsung 三星 | 当前型号 | 当前型号 |
CL21B154KBFNNNE 三星 | 完全替代 | CL32B154KBFNNNE和CL21B154KBFNNNE的区别 |
CL31B154KBCNNNC 三星 | 功能相似 | CL32B154KBFNNNE和CL31B154KBCNNNC的区别 |
CL32B154KCFNNNE 三星 | 功能相似 | CL32B154KBFNNNE和CL32B154KCFNNNE的区别 |
