Samsung 1210 MLCC 系列卷装### 1210 系列
1210 MLCC 系列卷装
得捷:
CAP CER 10000PF 500V X7R 1210
欧时:
Samsung Electro-Mechanics CL 系列 10nF 500V dc X7R电介质 表面安装器件 多层陶瓷电容器 CL32B103KGFNNNE
艾睿:
Since this CL32B103KGFNNNE multilayer ceramic capacitor from Samsung Electro-Mechanics has multiple layers of dielectric and electrodes, you&s;ll be getting high stability and low losses for resonant circuit applications. It can withstand a voltage of 500 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This product is 3.2 mm long, 1.25 mm tall and 2.5 mm deep. It has a tolerance of 10%. Its capacitance value is 0.01uF.
TME:
Capacitor: ceramic; 10nF; 500V; X7R; ±10%; SMD; 1210
Verical:
Cap Ceramic 0.01uF 500V X7R 10% Pad SMD 1210 125C T/R
儒卓力:
**KC 10nF 1210 10% 500V X7R **
Win Source:
CAP CER 10000PF 500V X7R 1210
额定电压DC 500 V
工作电压 500 V
电容 10 nF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 500 V
安装方式 Surface Mount
封装公制 3225
封装 1210
长度 3.2 mm
宽度 2.5 mm
高度 1.25 mm
封装公制 3225
封装 1210
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
温度系数 ±15 %
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CL32B103KGFNNNE Samsung 三星 | 当前型号 | 当前型号 |
CL32B103KGFNNNF 三星 | 类似代替 | CL32B103KGFNNNE和CL32B103KGFNNNF的区别 |
C1210C103KCRACAUTO 基美 | 功能相似 | CL32B103KGFNNNE和C1210C103KCRACAUTO的区别 |
