MLCC-多层陶瓷电容器
MLCC-多层陶瓷器
得捷:
CAP CER 8.2PF 25V C0G/NP0 0201
艾睿:
Do you need a non-polarized capacitor? This CL03C8R2BA3GNNC multilayer ceramic capacitor from Samsung Electro-Mechanics can be connected either to positive or to negative voltage as you please! It can withstand a voltage of 25 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This product is 0.6 mm long, 0.3 mm tall and 0.3 mm deep. Its capacitance value is 8.2pF.
额定电压DC 25.0 V
电容 8.2 pF
容差 ±0.1 pF
电介质特性 C0G/NP0
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 25 V
安装方式 Surface Mount
封装公制 0603
封装 0201
长度 0.6 mm
宽度 0.3 mm
高度 0.3 mm
封装公制 0603
封装 0201
厚度 0.3 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CL03C8R2BA3GNNC Samsung 三星 | 当前型号 | 当前型号 |
CL03C8R2CA3GNNC 三星 | 类似代替 | CL03C8R2BA3GNNC和CL03C8R2CA3GNNC的区别 |
GJM0335C1E8R2BB01D 村田 | 类似代替 | CL03C8R2BA3GNNC和GJM0335C1E8R2BB01D的区别 |
C0603C0G1E8R2B030BG 东电化 | 类似代替 | CL03C8R2BA3GNNC和C0603C0G1E8R2B030BG的区别 |
