MLCC-多层陶瓷电容器
MLCC-多层陶瓷器
得捷:
CAP CER 0.068UF 50V X7R 0805
艾睿:
This CL21B683KBFNNNE multilayer ceramic capacitor from Samsung Electro-Mechanics offers high stability and low losses for resonant circuit applications. It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has a tolerance of 10%. Its capacitance value is 0.068uF. This product is 2 mm long, 1.25 mm tall and 1.25 mm deep.
安富利:
Cap Ceramic 0.068uF 50V X7R 10% SMD 0805 125°C Embossed T/R
额定电压DC 50.0 V
电容 0.068 µF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 1.25 mm
封装公制 2012
封装 0805
厚度 1.25 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CL21B683KBFNNNE Samsung 三星 | 当前型号 | 当前型号 |
CL21B683KBCNNNC 三星 | 完全替代 | CL21B683KBFNNNE和CL21B683KBCNNNC的区别 |
CL21B683KBCNNND 三星 | 类似代替 | CL21B683KBFNNNE和CL21B683KBCNNND的区别 |
08055C683KAZ2A 艾维克斯 | 功能相似 | CL21B683KBFNNNE和08055C683KAZ2A的区别 |
