CL31 系列 1206 2200 pF 630 V NP0 ±5% 多层陶瓷电容
MLCC-多层陶瓷器
得捷:
CAP CER 2200PF 630V C0G/NP0 1206
艾睿:
Available with a variety of capacitance values, voltage ratings, package sizes, and other parameters, this CL31C222JHHNNNE multilayer ceramic capacitor from Samsung Electro-Mechanics can be used in multiple applications and for various purposes. It can withstand a voltage of 630 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 5%. Its capacitance value is 0.0022uF. This product is 3.2 mm long, 1.6 mm tall and 1.6 mm deep.
安富利:
Cap Ceramic 0.0022uF 630V C0G 5% SMD 1206 125°C Embossed T/R
富昌:
CL31 系列 1206 2200 pF 630 V NP0 ±5% 多层陶瓷电容
Verical:
Cap Ceramic 0.0022uF 630V C0G 5% Pad SMD 1206 125C T/R
额定电压DC 630 V
电容 0.0022 µF
容差 ±5 %
电介质特性 C0G/NP0
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 630 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 1.6 mm
封装公制 3216
封装 1206
厚度 1.6 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CL31C222JHHNNNE Samsung 三星 | 当前型号 | 当前型号 |
CL31C222JHHNFNE 三星 | 完全替代 | CL31C222JHHNNNE和CL31C222JHHNFNE的区别 |
CL31C222JHHNNNF 三星 | 完全替代 | CL31C222JHHNNNE和CL31C222JHHNNNF的区别 |
C3216C0G2J222J115AA 东电化 | 功能相似 | CL31C222JHHNNNE和C3216C0G2J222J115AA的区别 |
