CLM-114-02-L-D

Conn Socket Strip SKT 28POS 1mm Solder ST SMD Tube

28 位置 插座 0.039"（1.00mm） 表面贴装型 镀金

得捷:
CONN RCPT 28POS 0.039 GOLD SMD

艾睿:
Reduce safety concerns with this socket strip CLM-114-02-L-D header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This SKT connector&s;s 28 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. It has a socket type gender. Its pitch is 1 mm. This device has a maximum current rating of 2.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. CLM-114-02-L-D is housed in black liquid crystal polymer. It uses the solder termination method. This product is 14.31 mm long, 2.26 mm tall and 3.81 mm deep.

安富利:
Conn Socket Strip SKT 28 POS 1mm Solder ST SMD Tube

Newark:
# SAMTEC  CLM-114-02-L-D  Board-To-Board Connector, 1 mm, 28 Contacts, Receptacle, CLM Series, Surface Mount, 2 Rows

Win Source:
CONN RCPT 28POS 0.039 GOLD SMD / 28 Position Receptacle Connector 0.039" 1.00mm Surface Mount Gold
