CLM-105-02-F-D

板至板连接, 1 mm, 10 触点, 插座, CLM Series, 表面安装　, 2 排

10 Position Receptacle Connector Surface Mount

欧时:
1.00mm CLM Tiger Claw SMT socket, 10P

立创商城:
1mm

得捷:
CONN RCPT 10POS 0.039 GOLD SMD

e络盟:
PCB插座, 板至板, 1 mm, 2 排, 10 触点, 表面安装, Tiger Claw CLM Series

艾睿:
Protect your printed circuit boards from accidental damages with Samtec&s;s socket strip CLM-105-02-F-D header connector. This SKT connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. Its pitch is 1 mm. It has a socket type gender. It has a straight body orientation. This device has a maximum current rating of 2.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. CLM-105-02-F-D is housed in black liquid crystal polymer. This product is 5.31 mm long, 2.26 mm tall and 3.81 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Socket Strip SKT 10 POS 1mm Solder ST SMD Tube

Newark:
# SAMTEC  CLM-105-02-F-D  Board-To-Board Connector, 1 mm, 10 Contacts, Receptacle, CLM Series, Through Hole, 2 Rows
