CLT-110-02-G-D-BE

Conn Socket Strip SKT 20POS 2mm Solder ST SMD Tube

20 Position Receptacle, Bottom Entry Connector Surface Mount

欧时:
2.00 mm Socket CLT-110-02-G-D-BE

得捷:
CONN RCPT 20POS 0.079 GOLD SMD

艾睿:
Mounting this socket strip CLT-110-02-G-D-BE header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This SKT connector&s;s 20 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. Its pitch is 2 mm. It has a socket type gender. This device has a maximum current rating of 4.1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 20 mm long, 2.27 mm tall and 5.16 mm deep. CLT-110-02-G-D-BE is housed in black liquid crystal polymer.

安富利:
Conn Socket Strip SKT 20 POS 2mm Solder ST SMD Tube
