Conn Socket Strip SKT 12POS 1.27mm Solder ST SMD T/R
The CLP series from are Tiger Claw low profile rugged reliable dual wipe socket strips. These surface mount socket strips mates with Samtec FTSH, FTS and FW series of connectors.
- .
- Pitch spacing is 1.27mm 2 to 50 contacts per row with double row -D
- .
- High operating temperature range of -55°C to 125°C
- .
- Contact material is phosphor bronze
- .
- Black liquid crystal polymer insulator material
- .
- Voltage rating is 240VAC/340VDC
- .
- Complies with UL E111594 standard
- .
- Gold flash plated contacts
触点数 12
极性 Female
触点电镀 Gold
额定电流 3.3A/触头
排数 2
针脚数 12
拔插次数 100
额定电流Max 3.4A/触头
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 240VAC, 330VDC
接触电阻Max 10 mΩ
安装方式 Surface Mount
高度 2.29 mm
外壳颜色 Black
触点材质 Phosphor Bronze
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Industrial, -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CLP-106-02-F-D-TR Samtec 申泰电子 | 当前型号 | 当前型号 |
CLP-106-02-F-D 申泰电子 | 完全替代 | CLP-106-02-F-D-TR和CLP-106-02-F-D的区别 |
CLP-106-02-F-D-K-TR 申泰电子 | 完全替代 | CLP-106-02-F-D-TR和CLP-106-02-F-D-K-TR的区别 |
M50-3150642R Harwin | 功能相似 | CLP-106-02-F-D-TR和M50-3150642R的区别 |
