CLE-105-01-G-DV-A-TR

Conn Socket Strip SKT 10POS 0.8mm Solder ST SMD T/R

10 位置 插座，通透式 0.031"（0.80mm） 表面贴装型 镀金

欧时:
0.80 mm Tiger Beam Cost-effective Single

得捷:
CONN RCPT 10POS 0.031 GOLD SMD

立创商城:
0.8mm

艾睿:
Thanks to Samtec&s;s socket strip CLE-105-01-G-DV-A-TR header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This SKT connector&s;s 10 contacts that are made out of beryllium copper and plated with gold over nickel. It has a socket type gender. Its pitch is 0.8 mm. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 2.7 A/contact. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It uses the solder termination method. This product is 4 mm long, 3.3 mm tall and 4.83 mm deep. This connector has an operating temperature of -55 to 125 °C. CLE-105-01-G-DV-A-TR is housed in black liquid crystal polymer.

安富利:
Conn Socket Strip SKT 10 POS 0.8mm Solder ST SMD T/R

Verical:
Conn Socket Strip SKT 10 POS 0.8mm Solder ST SMD T/R

Newark:
# SAMTEC  CLE-105-01-G-DV-A-TR  Board-To-Board Connector, 0.8 mm, 10 Contacts, Receptacle, CLE Series, Surface Mount, 2 Rows
