CLM-116-02-F-D

SAMTEC CLM-116-02-F-D Board-To-Board Connector, 1mm, 32Contacts, Receptacle, CLM Series, Through Hole, 2Rows

32 位置 插座 0.039"（1.00mm） 表面贴装型 镀金

得捷:
CONN RCPT 32POS 0.039 GOLD SMD

欧时:
1.00 mm Socket 32 P 2 Row F Au

艾睿:
As an added safety precaution, the socket strip CLM-116-02-F-D header connector from Samtec will prevent and protect components on your circuit board from accidentally touching each other. This SKT connector&s;s 32 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 1 mm. This is a 2-row connector. It has a straight body orientation. It has a socket type gender. This device has a maximum current rating of 2.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. CLM-116-02-F-D is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 16.31 mm long, 2.26 mm tall and 3.81 mm deep.

安富利:
Conn Socket Strip SKT 32 POS 1mm Solder ST SMD Tube

Verical:
Conn Micro Socket Strip SKT 32 POS 1mm Solder ST SMD Tube

Newark:
# SAMTEC  CLM-116-02-F-D  Board-To-Board Connector, 1 mm, 32 Contacts, Receptacle, CLM Series, Through Hole, 2 Rows
