CLM-106-02-L-D

Conn Socket Strip SKT 12POS 1mm Solder ST SMD Tube

12 Position Receptacle Connector Surface Mount

得捷:
CONN RCPT 12POS 0.039 GOLD SMD

立创商城:
1mm

艾睿:
Think of Samtec&s;s socket strip CLM-106-02-L-D header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This SKT connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 1 mm. It has a socket type gender. It has a straight body orientation. This is a 2-row connector. This device has a maximum current rating of 2.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. CLM-106-02-L-D is housed in black liquid crystal polymer. This product is 6.31 mm long, 2.26 mm tall and 3.81 mm deep. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Socket Strip SKT 12 POS 1mm Solder ST SMD Tube

Newark:
# SAMTEC  CLM-106-02-L-D  Board-To-Board Connector, 1 mm, 12 Contacts, Receptacle, CLM Series, Surface Mount, 2 Rows
