CLM-104-02-F-D-BE

SAMTEC CLM-104-02-F-D-BE Board-To-Board Connector, 1mm, 8Contacts, Receptacle, CLM Series, Through Hole, 2Rows

8 Position Receptacle, Bottom Entry Connector Surface Mount

得捷:
CONN RCPT 8POS 0.039 GOLD SMD

艾睿:
Use this socket strip CLM-104-02-F-D-BE header connector from Samtec where IDC ribbon cables are used. This SKT connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 1 mm. This is a 2-row connector. It has a straight body orientation. It has a socket type gender. This device has a maximum current rating of 2.8 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 4.31 mm long, 2.26 mm tall and 3.81 mm deep. It uses the solder termination method. CLM-104-02-F-D-BE is housed in black liquid crystal polymer.

安富利:
Conn Socket Strip SKT 8 POS 1mm Solder ST SMD

Newark:
# SAMTEC  CLM-104-02-F-D-BE  Board-To-Board Connector, 1 mm, 8 Contacts, Receptacle, CLM Series, Through Hole, 2 Rows
