Cap Ceramic 560pF 50V C0G 2% SMD 0603 125℃ Paper T/R
SMD Comm C0G, Ceramic, Commercial Grade, 560 pF, 2%, 50 VDC, C0G, SMD, MLCC, Ultra-Stable, Low Loss, Class I, 0603
立创商城:
560pF ±2% 50V
得捷:
CAP CER 560PF 50V NP0 0603
艾睿:
This C0603C561G5GACTU multilayer ceramic capacitor from Kemet is non-polarized so it may be connected either to positive or to negative voltage. It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. Its capacitance value is 560pF. It has a tolerance of 2%. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep.
安富利:
Cap Ceramic 560pF 50V C0G 2% SMD 0603 125°C Paper T/R
额定电压DC 50.0 V
绝缘电阻 100 GΩ
电容 560 pF
容差 ±2 %
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 1608
封装 0603
引脚间距 0.7 mm
长度 1.6 mm
宽度 1.6 mm
高度 0.8 mm
封装公制 1608
封装 0603
引脚间距 0.7 mm
介质材料 Ceramic
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C0603C561G5GACTU KEMET Corporation 基美 | 当前型号 | 当前型号 |
C0603C561K5GACTU 基美 | 类似代替 | C0603C561G5GACTU和C0603C561K5GACTU的区别 |
0603N561G500CT 台湾华科 | 类似代替 | C0603C561G5GACTU和0603N561G500CT的区别 |
C0603C561J5GACTU 基美 | 功能相似 | C0603C561G5GACTU和C0603C561J5GACTU的区别 |
