C274AC34400AA0J概述

KEMET  C274AC34400AA0J  膜电容, C27系列, 4 µF, ± 5%, PP聚丙烯, 470 V, 罐型

The Kemet C27.4 series are plastic can packaged film capacitors for AC motor applications. These capacitors are used in series with the start winding of the single phase electric motor, allowing its starting and increasing the torque during operation. Main application fields include air fans, pumps, circulators and low power electric motors. The choice of the capacitor depends on expected life length and the mechanical connection of the user.

.
Capacitance value ranges from 1µF to 60µF
.
Polypropylene is used as a dielectric
.
Operating temperature range -25 to 85°C
.
Rated voltage of 470VAC
.
±5% standard tolerance
C274AC34400AA0J中文资料参数规格
技术参数

额定电压DC 470 V

额定电压AC 470 V

额定电流 590 mA

电容 4 µF

容差 ±5 %

工作温度Max 85 ℃

工作温度Min -25 ℃

额定电压 470 V

封装参数

安装方式 Quick Connect

封装 罐型

外形尺寸

长度 56.5 mm

高度 56.5 mm

封装 罐型

物理参数

介质材料 Polypropylene

工作温度 -25℃ ~ 85℃

其他

产品生命周期 Active

包装方式 Bulk

制造应用 Power Management, 工业, Industrial, 便携式器材, 电机运行;电机启动, Motor Run; Motor Start, 电机驱动与控制, Consumer Electronics, Portable Devices, 电源管理, Motor Drive & Control, 消费电子产品

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

REACH SVHC标准 No SVHC

REACH SVHC版本 2015/06/15

数据手册

在线购买C274AC34400AA0J
型号: C274AC34400AA0J
描述:KEMET  C274AC34400AA0J  膜电容, C27系列, 4 µF, ± 5%, PP聚丙烯, 470 V, 罐型
替代型号C274AC34400AA0J
型号/品牌 代替类型 替代型号对比

C274AC34400AA0J

KEMET Corporation 基美

当前型号

当前型号

MR/P/440/4/C

LCR

功能相似

C274AC34400AA0J和MR/P/440/4/C的区别
