CDPH 系列 33 uH 20 % 容差 0.43 A 屏蔽型 表面贴装 功率电感
33 µH 屏蔽 - 器 1.25 A 200 毫欧最大 非标准
得捷:
FIXED IND 33UH 1.25A 200MOHM SMD
立创商城:
33uH ±20% 430mA 160mΩ
艾睿:
This power CDPH4D19FNP-330MC surface mount inductor from Sumida Corporation is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -40 °C to 105 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 5.2 mm long, 2 mm tall and 5.2 mm deep. This device utilizes drum core technology. Its test frequency is 100K Hz. This SMD inductor has a maximum DC current of 1.25 A with a maximum resistance of 200m Ohm. It has a tolerance of 20%. It has an inductance of 33u H.
安富利:
Ind Power Shielded Wirewound 33uH 20% 100KHz Ferrite 1.25A 2020 Carrier T/R
Verical:
Inductor Power Shielded Drum Core 33uH 20% 100KHz Ferrite 1.25A 200mOhm DCR 2020 T/R
