CDRH127NP-331MC

CDRH 系列 330 uH 20 % 容差 0.95 A 屏蔽 表面贴装 功率电感

330µH Shielded Inductor 950mA 640mOhm Max Nonstandard

得捷:
FIXED IND 330UH 950MA 640MOHM SM

立创商城:
330uH ±20% 950mA 640mΩ

艾睿:
An ideal space-saving electronic component is this power CDRH127NP-331MC surface mount inductor from Sumida Corporation. This SMD inductor has an operating temperature range of -40 °C to 100 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has a tolerance of 20%. It has an inductance of 330u H. This SMD inductor has a maximum DC current of 950m A with a maximum resistance of 640m Ohm. Its test frequency is 1K Hz. This product is 12.3 mm long, 8 mm tall and 12.3 mm deep. This device utilizes drum core technology.

安富利:
Ind Power Shielded Wirewound 330uH 20% 1KHz Ferrite 950mA Carrier T/R

Chip1Stop:
Inductor Power Shielded Drum Core 330uH 20% 1KHz Ferrite 950mA 640mOhm DCR Carrier T/R

Verical:
Inductor Power Shielded Drum Core 330uH 20% 1KHz Ferrite 950mA 640mOhm DCR T/R

儒卓力:
**CDRH127NP 330uH 950mA 20% WWT **
