DAC 2CH Delta-Sigma 24Bit 16Pin SOIC
Description
The CS4340A is a complete stereo digital-to-analog system including digital interpolation, fourth-order delta sigma digital-to-analog conversion, digital de-emphasis and switched capacitor analog filtering. The advantages of this architecture include: ideal differential linearity, no distortion mechanisms due to resistor matching errors, no linearity drift over time and temperature, and a high tolerance to clock jitter.
Features
! 101 dB Dynamic Range
! -91 dB THD+N
! +3.3 V or +5 V Power Supply
! 50 mW with 3.3 V supply
! Low Clock JitterSensitivity
! Filtered Line Level Outputs
! On-Chip Digital De-emphasis for 44.1 kHz
! Popguard® Technology for Control of Clicks and Pops
! Up to 200 kHz Sample Rates
! Automatic Mode Detection for Sample Rates between 4 and 200 kHz
! Pin Compatiblewith the CS4340
