ADC Dual Delta-Sigma 192KSPS 24Bit Serial 24Pin SOIC T/R
ADC, Audio 24 b 192k Serial 24-SOIC
得捷:
IC ADC/AUDIO 24BIT 192K 24SOIC
安富利:
The CS5351 is a complete analog-to-digital converterfor digital audio systems. It performs sampling, analogto-digitalconversion, and anti-alias filtering. The devicegenerates 24-bit values for both left and right inputs inserial form at sample rates up to 192 kHz per channel.The CS5351 uses a 5th-order, multi-bit, delta-sigmamodulator followed by digital filtering and decimation,which removes the need for an external anti-alias filter.The ADC uses a differential architecture which providesexcellent noise rejection.The CS5351 is ideal for audio systems requiring widedynamic range, negligible distortion, and low noise.Such applications include A/V receivers, DVD-R, CD-R,digital mixing consoles, and effects processors.
AMEYA360:
IC ADC 24BIT SRL 192KHZ 24-SOIC
