Samsung 1206 MLCC seriesHighly reliable tolerance and high speed automatic chip placement on PCBs Wide capacitance range Wide temperature compensation and voltage range: from C0G to Y5V and from 6.3V to 50V Highly reliable performance Highly resistant termination metal Applications include: HHP, DSC, DVC, LCD, TV, Memory Module, PDA, Game Machine; Tuner Product code C is suitable. For using special purpose like Military, Medical, Aviation, Automobile device should be following a special specification ### 1206 系列C0G NP0 是温度补偿的最常见配方,为 EIA I 类陶瓷材料 X7R 配方称为温度稳定陶瓷,属于 EIA II 类材料 Y5V 配方为有限温度范围内的一般用途材料。这些特征使得 Y5V 非常适合去耦应用。
MLCC-多层陶瓷器
得捷:
CAP CER 2.2UF 16V X7R 1206
欧时:
### Samsung 1206 MLCC seriesHighly reliable tolerance and high speed automatic chip placement on PCBs Wide capacitance range Wide temperature compensation and voltage range: from C0G to Y5V and from 6.3V to 50V Highly reliable performance Highly resistant termination metal Applications include: HHP, DSC, DVC, LCD, TV, Memory Module, PDA, Game Machine; Tuner Product code C is suitable. For using special purpose like Military, Medical, Aviation, Automobile device should be following a special specification ### 1206 系列C0G NP0 是温度补偿的最常见配方,为 EIA I 类陶瓷材料 X7R 配方称为温度稳定陶瓷,属于 EIA II 类材料 Y5V 配方为有限温度范围内的一般用途材料。这些特征使得 Y5V 非常适合去耦应用。
艾睿:
Cap Ceramic 2.2uF 16V X7R 10% Pad SMD 1206 125°C T/R
安富利:
Cap Ceramic 2.2uF 16V X7R 10% SMD 1206 125°C Embossed T/R
儒卓力:
**KC 2,2uF 1206 10% 16V X7R **
额定电压DC 16.0 V
电容 2.2 µF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 16 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 1.6 mm
封装公制 3216
封装 1206
厚度 1.6 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
温度系数 ±15 %
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 Yes
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CL31B225KOHNNNF Samsung 三星 | 当前型号 | 当前型号 |
CL31B225KOHNNNE 三星 | 完全替代 | CL31B225KOHNNNF和CL31B225KOHNNNE的区别 |
EMK316B7225KLHT 太诱 | 类似代替 | CL31B225KOHNNNF和EMK316B7225KLHT的区别 |
C1206C225K4RAC 基美 | 类似代替 | CL31B225KOHNNNF和C1206C225K4RAC的区别 |
