C637C103MHR5TA

C637C103MHR5TA图片1
C637C103MHR5TA图片2
C637C103MHR5TA概述

10nF ±20% 3kV X7R

Multilayer ceramic capacitors are available in a variety of physical sizes and configurations, including leaded devices and surface mounted chips. Leaded styles include molded and conformally coated parts with axial and radial leads. However, the basic capacitor element is similar for all styles. It is called a chip and consists of formulated dielectric materials which have been cast into thin layers, interspersed with metal electrodes alternately exposed on opposite edges of the laminated structure. The entire structure is fired at high temperature to produce a monolithic block which provides high capacitance values in a small physical volume. After firing, conductive terminations are applied to opposite ends of the chip to make contact with the exposed electrodes. Termination materials and methods vary depending on the intended use.

C637C103MHR5TA中文资料参数规格
技术参数

额定电压DC 3 kV

电容 0.01 µF

容差 ±20 %

工作温度Max 125 ℃

工作温度Min -55 ℃

额定电压 3000 V

封装参数

封装 Radial

引脚间距 9.52 mm

外形尺寸

长度 11.9 mm

宽度 0.1 in

高度 10.2 mm

封装 Radial

引脚间距 9.52 mm

物理参数

材质 X7R/-55℃~+125℃

工作温度 -55℃ ~ 125℃

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准

含铅标准 Lead Free

数据手册

在线购买C637C103MHR5TA
型号: C637C103MHR5TA
描述:10nF ±20% 3kV X7R
