CS5101A-JL8

Analog to Digital Converters - ADC IC 16Bit 100/20kHz ADC

Description

The CS5101A and CS5102A are 16-bit monolithic CMOS analog-to-digital converters capable of 100 kHz 5101A and 20 kHz 5102A throughput. The CS5102A’s low power consumption of 44 mW, coupled with a power down mode, makes it particularly suitable for battery powered operation.

Features

Monolithic CMOS A/D Converters

\- Inherent Sampling Architecture

\- 2-Channel Input Multiplexer

\- Flexible Serial Output Port

Ultra-Low Distortion

\- S/N+D: 92 dB

\- THD: 0.001%

Conversion Time

\- CS5101A: 8 µs

\- CS5102A: 40 µs

Linearity Error: ±0.001% FS

\- Guaranteed No Missing Codes

Self-Calibration Maintains Accuracy

\- Over Time and Temperature

Low Power Consumption

\- CS5101A: 320 mW

\- CS5102A: 44 mW

\- Power-down Mode: <1 mW

Evaluation Board Available
