CKN6-40/1N/B/003中文资料参数规格
物理参数
工作温度 -25℃ ~ 40℃
其他
Protection type RCBO breaker
Rated current 40A
Residual current 0.03A
Max surge current 250A
Number of poles 1+N
Rated voltage 230V
Mounting DIN
Sealing IP40
Cross section of connecting wires 1...25mm2
Circuit breaker kind type AC
Operating temperature -25...40°C
Short circuit breaking capacity 6kA
Mechanical durability 4000cycles
Characteristics B
Thickness of connecting busbars 0.8...2mm
Dimensions see
符合标准
RoHS标准 RoHS Compliant
在线购买CKN6-40/1N/B/003
型号： CKN6-40/1N/B/003
制造商：
Eaton Bussmann
伊顿巴斯曼
描述：RCBO breaker; Inom:40A; Ires:30mA; Max surge current:250A; 230V
