Circuit Breaker; Hyd/Mag; Handle; 3P; SeriesTrip; 50/60Hz Med; 20A; Stud; Dual Legend
** C-Series Circuit Breakers**
Carling Technologies C-Series hydraulic/magnetic circuit breakers are ideal for applications that require higher amperage and voltage handling capability in a compact package. They are available in 1-6 poles, 0.02-100 amps, up to 480 V ac or 150 V dc, with choice of time delays, terminal options, actuator styles and Colors. The C-Series employs a unique arc chute design which allows for higher interrupting capacities of up to 10,000 amps. A thermoset glass filled polyester half shell construction provides for increased mechanical and electrical strength. The wiping contacts, mechanical linkage with two step actuation, and clean contacts provide high, positive contact pressure and longer contact life.
额定电流 20 A
额定电压 277VAC, 480VAC
Actuator Type Handle
Brand/Series C Series
Current Rating 20 A
Dimensions 2.475 L x 2.265 W x 2.5 H in.
Mounting Type Threaded Neck
Number of Poles 3 Pole
Primary Type Circuit Breaker
Special Features CSA Certified/UL489 Listed
Termination Stud
Time, Trip Medium Delay
Type Hydraulic/Magnetic
Voltage Rating 480 WE/277 VAC; 240 VAC, 125 VDC UL 489
RoHS标准 RoHS Compliant
