DS1100Z-125+T

Active Tapped Delay Line 5 TAP 1IN 25ns ABS 125ns MAX 8Pin SOIC N T/R

延迟线 IC 不可编程 抽头 125ns 8-SOIC（0.154"，3.90mm 宽）

得捷:
IC DELAY LINE 5TAP 125NS 8SOIC

安富利:
The DS1100 series delay lines have five equally spaced taps providing delays from 4ns to 500ns. These devices are offered in surface-mount packages to save PCB area. Low cost and superior reliability over hybrid technology is achieved by the combination of a 100% silicon delay line and industry-standard µMAX® and SO packaging. The DS1100 5-tap silicon delay line reproduces the input-logic state at the output after a fixed delay as specified by the extension of the part number after the dash. The DS1100 is designed to reproduce both leading and trailing edges with equal precision. Each tap can drive up to 10 74LS loads.Maxim can customize standard products to meet special needs.
