D6R90 F2 LFS

SWITCH PUSH SPST-NO 0.1A 32V

按钮 SPST-NO 按键开关 通孔

得捷:
SWITCH PUSH SPST-NO 0.1A 32V

立创商城:
D6R90 F2 LFS

艾睿:
By simply turning a key, you can easily power your project on or off using the D6R90F2LFS key switch from C&a;K Components. This round button actuator is 7 mm long. It has a SPST configuration. This part has a minimum operating temperature of -20 °C and a maximum of 85 °C. It has 4 terminals. The D6R90F2LFS part has a PC pin termination style. This product is 11.4 mm long, 14.3 mm tall and 12 mm deep. This product&s;s terminal pitch is 5 mm. The maximum DC voltage rating is 32 VDC.
