TEXAS INSTRUMENTS DRV5053EAQLPG 霍尔效应传感器, 双极性, 2.3 mA, TO-92, 3 引脚, 2.5 V, 38 V
By using it to detect a magnetic field, this Hall effect sensor from Texas Instruments can then act as a proximity switch, speed detector, or current sensor. This device"s minimum operating supply voltage of 2.5 V, while its maximum is 38 V. This part has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product comes packaged in bulk, so the parts will be stored loosely.
电源电压DC 2.50V min
输出电流 2.3 mA
针脚数 3
带宽 20 kHz
输出电流Max 2.3 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2.7V ~ 38V
电源电压Max 38 V
电源电压Min 2.5 V
安装方式 Through Hole
引脚数 3
封装 TO-226-3
封装 TO-226-3
工作温度 -40℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
