微控制器, H8S Family H8S/2100 Series Microcontrollers, H8S/2000, 16位, 20 MHz, 128 KB, 4 KB
H8S/2000 series IC 16 位 20MHz 128KB（128K x 8） 闪存 80-QFP（14x14）
得捷:
IC MCU 16BIT 128KB FLASH 80QFP
立创商城:
其他系列 20MHz 闪存：128K@x8bit RAM：4KB
e络盟:
微控制器, H8S Family, H8S/2100 Series, H8S/2138 Group Microcontrollers, H8S/2000, 16位, 20 MHz, 128 KB
艾睿:
This DF2138AFA20V microcontroller from Renesas will make your CPU more versatile and quick. This microcontroller has a minimum operating temperature of -20 °C and a maximum of 75 °C. It has a maximum clock speed of 20 MHz. This device has a typical operating supply voltage of 3.3|5 V. Its minimum operating supply voltage of 3 V, while its maximum is 5.5 V. Its ADC resolution is 10, while its DAC resolution is 8. This is a 16 bit processor. Its flash program memory is 128KB.
安富利:
MCU 16-bit/32-bit H8S CISC 128KB Flash 3.3V/5V 80-Pin PQFP
Chip1Stop:
MCU 16-bit H8S CISC 128KB Flash 3.3V/5V 80-Pin PQFP
Verical:
MCU 16-bit H8S/2000 CISC 128KB Flash 3.3V/5V 80-Pin PQFP Tray
频率 20 MHz
电源电压DC 5.00 V, 5.50 V max
针脚数 80
时钟频率 20.0 MHz, 20.0 MHz max
RAM大小 4 KB
位数 16
I/O引脚数 55
存取时间 20.0 µs
模数转换数ADC 1
输入/输出数 58 Input
工作温度Max 75 ℃
工作温度Min -20 ℃
数模转换数DAC 1
电源电压Max 3.6 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 80
封装 QFP-80
封装 QFP-80
工作温度 -20℃ ~ 75℃
产品生命周期 Unknown
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
