MCU 16Bit/32Bit H8S CISC 256KB Flash 3.3V/5V 128Pin PQFP
H8S/2600 series IC 16 位 25MHz 256KB（256K x 8） 闪存 128-QFP（14x20）
得捷:
IC MCU 16BIT 256KB FLASH 128QFP
艾睿:
Crucial to any electronic system is this DF2633F25V microcontroller from Renesas, a mini computer that can be programmed to do whatever you want. This microcontroller has an operating temperature range of -20 °C to 75 °C. It has a maximum clock speed of 25 MHz. This device has a typical operating supply voltage of 3.3|5 V. Its minimum operating supply voltage of 3|4.5 V, while its maximum is 3.6|5.5 V. Its flash program memory is 256KB. Its ADC resolution is 10, while its DAC resolution is 8. This is a 16|32 bit processor.
安富利:
MCU 16-bit/32-bit H8S CISC 256KB Flash 3.3V/5V 128-Pin PQFP
Chip1Stop:
MCU 16-Bit/32-Bit H8S CISC 256KB Flash 3.3V/5V 128-Pin PQFP
Verical:
MCU 16-bit H8S/2600 CISC 256KB Flash 3.3V/5V 128-Pin PQFP Tray
Win Source:
IC MCU 16BIT 256KB FLASH 128QFP
频率 25 MHz
电源电压DC 3.30 V, 3.60 V max
时钟频率 25.0 MHz, 25.0 MHz max
RAM大小 16K x 8
位数 16, 32
FLASH内存容量 256 KB
I/O引脚数 73
存取时间 25.0 µs
模数转换数ADC 1
工作温度Max 75 ℃
工作温度Min -20 ℃
数模转换数DAC 1
安装方式 Surface Mount
引脚数 128
封装 QFP-128
封装 QFP-128
工作温度 -20℃ ~ 75℃
产品生命周期 Unknown
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
香港进出口证 NLR
