Switch, pushbtn; Interlock; SPDT, Mom; 10A 125VAC; Short act; Snap-in mnt; 0.25in. QC
DS Series interlock pushbuttons can be applied as door, interlock, detection and circuit interrupt switches. Choice of momentary or momentary/pull operations available.
立创商城:
DS1D6AQ3
贸泽:
Pushbutton Switches SPDT 10A 125/250 Vac Short Button Q.C.
艾睿:
Switch Safety Interlock N.O./N.C. SPDT Short Button 10A 250VAC 248.57VA 4.17N Panel Mount Quick Connect
Allied Electronics:
Switch, pushbtn; Interlock; SPDT, Mom; 10A 125VAC; Short act; Snap-in mnt; 0.25in. QC
Verical:
Switch Safety Interlock N.O./N.C. SPDT Short Button 10A 250VAC 248.57VA 4.17N Panel Mount Quick Connect
MASTER:
Interlock Pushbutton Switch
Electro Sonic:
Interlock Pushbutton Switch
额定电压AC 125V, 250V
额定电流 10 A
针脚数 2
额定电流Max 10A @250VAC
额定功率Max 248.57 VA
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压 125 VAC
额定电压AC Max 250 V
接触电阻Max 30 mΩ
安装方式 Panel
封装 -
长度 31.75 mm
宽度 17.3 mm
高度 39.72 mm
封装 -
颜色 White
触点材质 Silver Alloy
工作温度 -40℃ ~ 85℃
产品生命周期 50000 Cycles
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
