DS34LV86TMX/NOPB

DS34LV86TMX/NOPB 编带

The DS34LV86T is a high speed quad differential CMOS receiver that meets the requirements of both A/EIA-422-B and ITU-T V.11. The CMOS DS34LV86T features typical low static ICC of 9 mA which makes it ideal for battery powered and power conscious applications. The Tri-State enables, EN, allow the device to be disabled when not in use to minimize power consumption. The dual enable scheme allows for flexibility in turning receivers on and off.

The receiver output RO is ensured to be High when the inputs are left open. The receiver can detect signals as low as ±200 mV over the common mode range of ±10V. The receiver outputs RO are compatible with TTL and LVCMOS levels.
