DRV134UAE4

音频平衡线路驱动器 AUDIO BALANCED LINE DRIVERS

The is a Differential Output Amplifier converts a single-ended input to a balanced output pair. This balanced audio driver consists of high performance op amps with on-chip precision resistors. It is fully specified for high performance audio applications and has excellent AC specifications, including low distortion 0.0005% at 1kHz and high slew rate 15V/µs. The on-chip resistors are laser-trimmed for accurate gain and optimum output common-mode rejection. Wide output voltage swing and high output drive capability allow use in a wide variety of demanding applications. They easily drive the large capacitive loads associated with long audio cables. Used in combination with the INA134 or INA137 differential receivers, it offers a complete solution for transmitting analogue audio signals without degradation.

.

Balanced output

.

High capacitive load drive capability

.

Improved replacement for SSM2142

.

0.0005% at f=1kHz Low distortion

.

17VRMS into 600R Wide output swing

.

15V/µs High slew rate

.

±5.2mA Low quiescent current

.

Green product and no Sb/Br
