DTC143EUAT106

NPN 100毫安50V数字晶体管（偏置电阻内置晶体管） NPN 100mA 50V Digital Transistors Bias Resistor Built-in Transistors

Features

1 Built-In Biasing Resistors, R1 = R2 = 4.7kW.

2 Built-in bias resistors enable the configuration of an inverter circuit without connecting external input resistors see inner circuit.

3 The bias resistors consist of thin-film resistors with complete isolation to allow negative biasing of the input. They also have the advantage of completely eliminating parasitic effects.

4 Only the on/off conditions need to be set for operation, making the circuit design easy.

5 Complementary PNP Types :DTA143E series

6 Lead Free/RoHS Compliant.

Application

  Switching circuit, Inverter circuit, Interface circuit, Driver circuit
