TDK LAMBDA DPP120-12-1 稳压电源, DIN导轨式 120W
* 5 to 48 V Outputs
* 50 mV Ripple and Noise
* Parallel Up to 3 Units 100 W and Up
* Convection Cooled from –10°C Up to +71°C
* Active Power Factor Correction PFC
* Universal/Auto Select AC Input
* Input Transient Protection IEC61000-4
* UL/CSA/EN60950-1 and CE Mark Safety Approvals
* UL1310 Class 2
* UL508 Listed and Class 1, Div. 2
得捷:
AC/DC DIN RAIL SUPPLY 12V 120W
贸泽:
DIN Rail Power Supplies 120W 12V 10A DIN Rail 115/230VAC
e络盟:
稳压电源, DIN导轨式 120W
艾睿:
With this DPP120-12-1 AC to DC power supply from TDK-Lambda your electronic device will be able to operate by using direct current instead of alternating current. It has a voltage of 12 V and maximum output power of 120 W. This part&s;s single output can handle a current up to 10 A. This part has a minimum operating temperature of -40 °C and a maximum of 71 °C.
Allied Electronics:
Power Supply; AC-DC; 12V; 10A; 93-132/186-264V In; Enclosed; DIN Rail; PFC; DPP Series
安富利:
AC/DC Power Supply Single-OUT 12V 10A 120W 9-Pin
Chip1Stop:
AC/DC Power Supply Single-OUT 12V 10A 120W 9-Pin
Verical:
AC/DC Power Supply Single-OUT 12V 10A 120W 9-Pin
Newark:
AC/DC DIN Rail Power Supply PSU, 1 Output, 120 W, 12 VDC, 10 A
频率 47Hz ~ 63Hz
额定功率 120 W
输出接口数 1
输出电压 12 V
输出电流 10 A
输出功率 120 W
输入电压DC Max 370 V
输入电压DC Min 210 V
输入电压AC Max 264 v
输入电压AC Min 93 v
额定电流Max 2.8 A
输出电流Max 10 A
输入电流Min 2.8 A
输出功率Max 120 W
工作温度Max 71 ℃
工作温度Min -40 ℃
额定电压 12 V
输入电压 90VAC ~ 132VAC, 186VAC ~ 264VAC
安装方式 DIN Rail
引脚数 9
长度 2.5 in
宽度 63.5 mm
高度 116.6 mm
产品生命周期 Active
制造应用 Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
DPP120-12-1 TDK 东电化 | 当前型号 | 当前型号 |
DPP120-12 东电化 | 类似代替 | DPP120-12-1和DPP120-12的区别 |
DR-120-12 台湾明纬 | 功能相似 | DPP120-12-1和DR-120-12的区别 |
TCL 120-112 Traco Electronic | 功能相似 | DPP120-12-1和TCL 120-112的区别 |
